Now you can connect Thunderbolt 3 computers to any kind of video equipment for building high-performance edit workstations, archiving from old broadcast decks, outputting broadcast graphics, and even live streaming! Simply connect your Blackmagic Ultrastudio to the Thunderbolt 3 port to get a wide range of video and audio connections that operate in all SD, HD, Ultra HD, and 4K DCI formats up to 60 frames per second! Connections include SDI, HDMI, and analog video and audio with broadcast quality 10‑bit YUV and 12-bit RGB in Apple ProRes and uncompressed file formats. UltraStudio Mini Recorder is designed to work with popular video software on Mac, Windows, and Linux such as DaVinci Resolve, Avid Media Composer, Adobe Premiere Pro, Final Cut Pro, and many more.
Blackmagic Design
UltraStudio
Model:HD Mini
UltraStudio
HD Mini
9420 E DoubleTree Ranch Rd #107
Pickup available, usually ready in 2 hours
9420 E DoubleTree Ranch Rd #107
Scottsdale AZ 85258
United States
Hurry and Save
- FREE Shipping for orders $150 above
- Add $25 for 2-day expedited shipping
- Ask about our Refer a Friend Program!
Got A Question? - Ask Our Team
Professional Capture andPlayback for Thunderbolt 3 Computers with the Ultrastudio Mini Recorder!
- SD/HD/3G-SDI and Analog Inputs
- HDMI and Dual SDI Outputs
- Thunderbolt 3 Interface
- Supports SD and HD Resolutions
- 4:2:2 and 4:4:4 Color Sampling Support
- 8/10/12-Bit Color Depth
- RS-422 Deck Control
- HD to SD Down-Conversion
Host Connection USB Type-C (Thunderbolt 3)
Input
Video Input Connectors 1 x BNC (3G-SDI) Female
1 x 3BNC (Component / Composite) Female
Input Video Format SDI (4:4:4/4:2:2)
DCI 2K at 23.98/24/25 fps
DCI 2KPsF 23.98/24/25 fps
1080p 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF 23.98/24/25/29.97/30 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
NTSC
PAL
Audio Input Connectors 2 x 1/4" TRS Analog Female
Embedded Audio Input SDI: 16-Channel
Output
Video Output Connectors 2 x BNC (3G-SDI) Female
1 x HDMI (HDMI 1.4b) Female
Output Video Format HDMI (8-Bit 4:4:4 RGB)
1080p at 30 fps
SDI (8/10/12-Bit 4:4:4 RGB)
1080p at 30 fps
Embedded Audio Output SDI: 16-Channel
HDMI: 2-Channel
Standards
Video Standard Compliance SMPTE 259M/292M/296M/372M/425M-A/425M-B
Connectivity
Other I/O 1 x DE-9/DB-9 RS-422 Input
1 x BNC Reference Input
Hardware
OS Compatibility Windows 7 or Later
macOS 10.14 or Later
Linux
*As of April, 2020: Check with manufacturer for the most up-to-date compatibility
Power Connector None
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Operating Humidity 0 to 90%
General
Dimensions 6.69 x 5.51 x 1.75" / 16.99 x 14 x 4.45 cm
Weight 1.34 lb / 608 g
