AIDA Imaging Broadcast/Conference NDI®|HX FHD NDI/IP/HDMI 18X Zoom PTZ Camera
AIDA Imaging Broadcast/Conference NDI®|HX FHD NDI/IP/HDMI 18X Zoom PTZ Camera
Black
9420 E DoubleTree Ranch Rd #107
9420 E DoubleTree Ranch Rd #107
Scottsdale AZ 85258
United States
Hurry and Save
- FREE Shipping for orders $150 above
- 2-day expedited shipping available
- Ask about our Refer a Friend Program!

Got A Question? - Ask Our Team
Perfect entry-level PTZ for new, and existing live streaming productions, the AIDA Imaging Broadcast/Conference NDI®|HX FHD NDI/IP/HDMI 18X Zoom PTZ Camera is equipped with a crystal clear 18X optical zoom, allowing for crisp 1080p imaging over HDMI, NDI|HX, and IP protocols simultaneously. Incorporate this into your live-streaming environment for simultaneous HDMI, IP, and NDI|HX streaming with a single device.
A 1/3" CMOS sensor captures up to 1080p video at 60 fps with vivid color in different light conditions. Utilize this PTZ camera with your standard VISCA, VISCA over IP, or NDI controllers. Overall, the PTZ-NDI-X18 gets the best NDI|HX performance per buck, without compromising the video quality.
- NDI®|HX streaming capable of low latency video streaming and PTZ control over NDI®|HX Protocol
- Full HD Progressive Scan sensor captures the sharp and vivid color under different light conditions
- Advanced digital image processor provides vivid and detailed images with full access feature sets
- Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur
- Simultaneous IP and HDMI outputs for versatility and seamless video performance
- Power Optical Zoom capability up to 18X
- 3.5mm Line-in for no audio/video delay over IP/NDI protocols
- Built-in OSD controls for customizable image settings
- Economically priced and perfect solutions for newer broadcast workflows
Video
Image Sensor | 1/3” Progressive CMOS |
Effective Pixels | Horizontal: 1920, Vertical: 1080 |
Pixel Size | 2.13 μm (H) x 2.13 μm (V) |
Resolution | 1080p & 1080i: 1920 x 1080 |
Resolution Rate | 1080 60p/59.94p/50p/30p/29.97p/25p/24p/23.98p 1080 60i/59.94i/50i 720 60p/59.94p/50p/30p/29.97p/25p |
Output | HDMI & NDI®|HX / RTSP / RTMP / SRT |
Color Space | 4:2:2 (YCbCr) 10bit |
Min Illumination | 0.1Lux |
Function
White Balance | Auto, Manual, Auto Tracking, One Push, Indoor, Outdoor |
Focus | Auto, Manual |
Shutter Speed | 1 to 1/10,000 Sec. |
Lens
Lens | 18X HD Optical Zoom |
Focus Length | 5.2~93mm |
F-Stop | F1.5 ~ F3.0 |
Viewing Angle | 60° (wide) ~ 4° (tell) |
PTZ
Pan/Tilt Speed Pan | 340°, Tilt: +90 to -30° |
Pan/Tilt Speed Pan | 0° to +120°/s, Tilt: 0° to +80°/s |
Presets | 128 Positions (via web) 10 Positions (via remote) |
Standard
IP Protocol | UDP/IP, RTSP/RTMP |
Audio
Input | 3.5mm TRS Stereo Audio Port |
Sample Rate | 16/24/32 Bits |
Physical
Camera Control | Protocol: VISCA, VISCA over IP, NDI Interface: RS-232C IN & OUT, RJ-45 Remote Controller |
Operation Temp | 32 °F - 104 °F |
Dimension | 155mm x 160m x 170mm / 6.10” x 6.92” x 6.69” |
Weight | 1.35kg / 2.97lbs |
Power | 12VDC (+9 - +15VDC) PoE+ (IEEE802.3at Standard Required) |
- AIDA Imaging Full HD NDI|HX Broadcast PTZ Camera with 18x Optical Zoom (Black or White)
- Remote Control
- Camera Mounting Bracket
- Power Adapter
- Power Cable
- Limited Warranty
